Use CERT UEFI Parser to open a firmware file, inspect its structure, and spot obvious red flags in about 20 to 30 minutes.
This is for sysadmins, security researchers, and curious homelab users who want a free way to examine UEFI update files without diving straight into raw hex.
Estimated time: 20 to 30 minutes for setup and a first test parse.

Quick Answer

Create a Python virtual environment, install cert-uefi-support and cert-uefi-parser, then run cert-uefi-parser --gui firmware.rom or cert-uefi-parser --json firmware.rom > output.json. The fastest first check is to search the parsed output for unusual strings such as DO NOT TRUST, which the SEI highlights in its PKFail case study.

CERT UEFI Parser is a free Python tool from the CERT Coordination Center that can parse firmware ROMs, PE files, installer packages, and related UEFI artifacts into text, JSON, SBOM-ready JSON, or a GUI view. That makes it a practical first-pass trick when you want to understand what is hiding inside a BIOS or UEFI update package.

What you need

  • Python 3 installed.
  • Basic comfort with Terminal, PowerShell, or Command Prompt.
  • A firmware-related file to inspect, such as a BIOS or UEFI update downloaded from your hardware vendor’s support page.
  • Optional: the PySide6 / Qt for Python GUI dependency, which is included when you install the [qt] extra.

Before you start

This tool helps you inspect firmware packages. It does not flash firmware, exploit vulnerabilities, or prove that a file is safe by itself. Think of it as a visibility trick: it turns a hard-to-read binary blob into something you can actually search, review, and compare.

How to use CERT UEFI Parser

1. Create a clean Python virtual environment

  1. Open Terminal or PowerShell.
  2. Create a virtual environment:
    python3 -m venv cert-venv
  3. Activate it.
    On macOS or Linux:
    source cert-venv/bin/activate
    On Windows PowerShell:
    cert-venv\Scripts\Activate.ps1

Expected check: Your prompt now shows the virtual environment name, or your shell confirms that cert-venv is active.

Reference: Python venv documentation.

2. Install the parser and its support package

  1. With the virtual environment active, run:
    pip install cert-uefi-support cert-uefi-parser[qt]
  2. If you only want command-line output and want a lighter install, use:
    pip install cert-uefi-support cert-uefi-parser

Expected check: Pip finishes without errors and you can run cert-uefi-parser --help.

The project’s GitHub instructions note that the Qt GUI dependency is optional because it is fairly large. That is normal, not a sign that something broke.

3. Download a firmware file you can inspect safely

  1. Go to your PC or motherboard vendor’s support page.
  2. Download a BIOS, firmware, or UEFI update package for a device you own or test in a lab.
  3. Save the file in an easy-to-find folder.

Expected check: You have a local firmware-related file such as a ROM image, capsule, executable updater, or vendor installer package.

CERT specifically notes that vendor support downloads are a practical place to get sample files for learning the tool.

4. Run your first parse

  1. In the same shell, move to the folder that contains your firmware file.
  2. For the GUI view, run:
    cert-uefi-parser --gui firmware-file-name
  3. For searchable JSON output, run:
    cert-uefi-parser --json firmware-file-name > output.json
  4. For a quick text view in the terminal, run:
    cert-uefi-parser --text firmware-file-name

Expected check: The tool opens a parsed structure in the GUI, prints readable sections in text mode, or generates a non-empty output.json file in JSON mode.

5. Search for obvious security clues

  1. If you used JSON mode, open output.json in your editor and search for strings such as DO NOT TRUST, certificate labels, module names, vendor identifiers, or suspiciously generic test data.
  2. If you used GUI mode, use the search feature to find matching class names or strings.
  3. Take note of anything that looks like a test key, development certificate, unexpected module, or repeated third-party component.

Expected check: You can move from “I have a blob” to “I can see named structures, strings, and certificates inside this file.”

The SEI’s PKFail case study shows this exact workflow by searching for the string DO NOT TRUST inside Lenovo ThinkServer firmware.

6. Export machine-readable output if you want to automate later

  1. Run:
    cert-uefi-parser --sbom firmware-file-name > sbom.json
  2. Keep that file for inventory, comparison, or later scripting.

Expected check: You get a non-empty JSON file that you can archive or feed into other workflows.

This is one of the more useful parts of the trick: once the firmware is in structured JSON, comparisons and repeat checks get much easier.

Why this trick is useful

  • You can inspect firmware packages without flashing them.
  • You get both human-friendly and script-friendly output.
  • It helps surface certificate strings, embedded modules, and vendor-specific structures faster than staring at raw binary data.
  • It is free, open source, and documented by CERT/CC.

Common mistakes

  • Skipping the virtual environment. Installing Python tooling globally is messy and makes troubleshooting harder.
  • Expecting every vendor package to parse perfectly. UEFI packaging varies a lot, so some files will be cleaner than others.
  • Thinking the GUI is required. The text and JSON modes are often enough for a first pass.
  • Treating one clean parse as a security verdict. This tool improves visibility, but it does not replace deeper analysis.
  • Using the wrong filename or path. Most first-run failures are just path mistakes. Classic terminal comedy.

Troubleshooting

The command is not found.
Make sure your virtual environment is active. Then run python -m pip show cert-uefi-parser to confirm the package installed in that environment.

The GUI will not open.
Install the Qt extra with pip install cert-uefi-parser[qt]. If you are on a headless server, use --text or --json mode instead.

The file parses oddly or incompletely.
Try a different vendor firmware package, especially a direct BIOS or UEFI update download from a mainstream hardware support page. Some installers wrap the interesting payload more heavily than others.

I want a faster way to compare multiple files.
Use --json or --sbom output, then compare those exports with your usual diff or scripting workflow.

Reference links

The bottom line

If you have ever wanted a simple first step into firmware analysis, this is a solid one. CERT UEFI Parser does not magically solve UEFI security, but it does turn opaque update files into something you can actually inspect, search, and learn from.

Next step: Grab one firmware update file from a lab machine or spare PC, run both --json and --gui mode, and compare which view helps you spot useful details faster.
